Description
Vigor 2865Lax-5G AX3000 wireless VDSL router with integrated 5G modem
DrayTek’s Vigor 2865 series Multi-WAN Firewall VPN routers are well-suited for Superfast VDSL Broadband and Ethernet¤based FTTP Fibre Broadband. Offering Gigabit throughput, Quality of Service, VPN client/server, comprehensive Firewall, and Content Filtering controls, the 2865 series stands out as one of the most versatile devices on the market, compatible with various network requirements.
The new Vigor 2865Lax-5G model integrates a 5G/LTE modem, enabling users to leverage mobile broadband effectively,
whether for failover or load-balanced broadband connections. Additionally, its Wi-Fi 6 module ensures rapid and efficient
wireless connectivity with DrayTek VigorAP access points and end devices.
VDSL and Ethernet Load Balancer
Connect the Vigor 2865 to Superfast Fibre with the integrated VDSL modem. Use the Ethernet WAN with Cable and Ultrafast FTTP. Load Balance multiple connections to boost performance.
Robust SMB VPN Router
Quickly and securely connect remote sites with up to 32 VPN tunnels. Enable remote workers to access resources with DrayTek SSL VPN and OpenVPN support.
5G/LTE Router with Dual Sim SlotIntegrated 5G/LTE modem on ‘5G’ models supporting LTE Category 19. Unlocked to any network. Backward compatible with 4G/LTE.
5+1 Gigabit LAN Ports
Link Server, Computers, and Network Attached Storage directly, with up to 6 Gigabit LAN ports. VLANs allow for as many as 8 separate networks, with options for Hotspot Captive Portal.
Wi-Fi 6 – AX3000 PerformanceWi-Fi 6 wireless provides gigabit Wi-Fi with reliable throughput. Ideal for time-sensitive video conferencing, low latency gaming and handling 4K Ultra-HD streaming, without buffering.
VigorACS SD-WAN Central Management
Manage the Vigor 2865 remotely and utilise DrayTek’s powerful SD-WAN features with the VigorACS 3 management platform. Centrally manage & provision whole networks across multiple sites.
Key Specification
• VDSL2 (Superfast Fibre) and Gigabit Ethernet WAN Router
• Multi-WAN Gigabit Performance Router with Load-Balancing & Failover
• Up to 950Mbps Firewall Throughput for Ethernet WAN
• 5+1 Gigabit RJ-45 LAN Ports
• Up to 800Mbps VPN Throughput with IPsec acceleration
• 32 LAN-to-LAN & Remote Teleworker VPN Tunnels
• 16 DrayTek SSL VPN or OpenVPN Tunnels
• 5G / LTE with Dual-SIMs for Second Backup Telco – New!
• AX3000 – Wi-Fi 6 Dual Band Wireless
• 8 LAN Subnets with VLANs (Port-based / 802.1q)
• SPI Firewall and Content Filtering
• Optional VigorCare Available
• Compatible with VigorACS Central Management Platform
What’s In The Box
Vigor 2865Lax-5G router
Quick Start Guide
Screws & wall plugs for wall mounting
2m Cat-5e RJ-45 Network Cable
2x Detachable Wireless LAN Antennas
4x Detachable LTE Antennas
4x 1m LTE Extension Base
DC 12V Power Supply with UK Plug
WAN connection
|
|
| 3G/4G USB modem compatibility | |
| DSL WAN | |
| Ethernet WAN | |
| SIM Card Slot | |
| WAN connection type | RJ-11,RJ-45,USB |
DSL features
|
|
| ADSL | |
| ADSL2+ | |
| VDSL | |
| VDSL2 | |
Security
|
|
| Access Control List (ACL) | |
| DDoS protection | |
| DMZ support | |
| DoS attack prevention | |
| Filtering | |
| Firewall | |
| IP address filtering | |
| MAC address filtering | |
| Network address translation (NAT) | |
| Parental control | |
| Schedule access | |
| Security algorithms | 3DES,AES,HTTPS,IPSec,MD5,MSCHAPv2,SHA-1,SHA-2,SHA-256,SNMP,SNMPv2,SNMPv3,SSH,SSL/TLS,TLS,WEP,WPA2,WPA2-AES,WPA2-Enterprise,WPA2-PSK,WPA2-Personal,WPA2-RADIUS,WPA2-TKIP,WPA3,WPA3-EAP,WPA3-Enterprise,WPA3-PSK,WPA3-Personal |
| Stateful Packet Inspection (SPI) | |
| System event log | |
| URL filtering | |
Antenna
|
|
| Antenna design | External |
| Antenna direction type | Omni-directional |
| Antennas quantity | 6 |
| Detachable antenna(s) | |
Network
|
|
| Automatic channel selection | |
| Dynamic DNS (DDNS) | |
| Ethernet LAN | |
| Ethernet LAN interface type | Gigabit Ethernet |
| Full duplex | |
| Number of guest networks (2.4 GHz) | 4 |
| Number of guest networks (5 GHz) | 4 |
| Port forwarding | |
| Port triggering | |
| SSID-based VLAN assignment | |
| Static route | |
| VPN server | IPsec, SSL, OpenVPN, WireGuard, PPTP, L2TP |
| VPN support | IPsec, SSL, OpenVPN, WireGuard, PPTP, L2TP |
| VPN tunnels quantity | 32 |
| Wireless Distribution System (WDS) bridge | |
Management features
|
|
| Bandwidth control | |
| Intelligent Mesh technology | |
| MIMO | |
| MU-MIMO technology | |
| Quality of Service (QoS) support | |
| Reset button | |
| WPS push button | |
| Wake-on-LAN ready | |
| Web-based management | |
| Wi-Fi Multimedia (WMM)/(WME) | |
Ports & interfaces
|
|
| DC-in jack | |
| Ethernet LAN (RJ-45) ports | 5 |
| RJ-11 ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB Port | |
Protocols
|
|
| DHCP client | |
| DHCP server | |
| Universal Plug and Play (UPnP) | |
Design
|
|
| Housing material | Plastic |
| Indication light | |
| On/off switch | |
| Product Type | Rack/wall router |
| Wall mountable | |
Operational conditions
|
|
| Operating relative humidity (H-H) | 10 – 90% |
| Operating temperature (T-T) | 0 – 45C |
Wireless LAN features
|
|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 3000Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
