Miele 80cm Built-in Induction Hob | KM7474

Description

Connectivity 3.0: Smart Control:

Concentrate fully on cooking: with Conctivity 3.0, your cooker hood always knows exactly what to do. As soon as the hob is switched on or off, the cooker hood responds automatically. The extraction power is automatically adjusted to what is happening on the hob, ensuring a pleasant room climate at all times. The appliances communicate with each other via WiFi. Conctivity 3.0 allows you to integrate the cooker hood and hob into Miele home.

Twinbooster: Booster Function For Rapid Heating:

For especially rapid heating: with Miele’s exclusive TwinBooster function, you can concentrate the power of two cooking zones into a single cooking zone if required. Or you can distribute the induction power individually for even more flexible cooking.

Convenient Additional Functions: Added Convenience

Added convenience when cooking: with the Stop & Go function all cooking zones can be reduced to power level 1 at the press of a button, allowing you to leave the hob unattended for a short time. The Keeping warm function keeps food at serving temperature. As an extra benefit, you can set the timer so the cooking zone will switch off automatically when the time has elapsed. The Recall function ensures that your settings are saved for 10 seconds.

Permanent Pan Detection: Set Down Your Pan and Get Cooking

All you have to do is switch on the hob – if there is already a pan on a cooking zone, the corresponding control element will be activated automatically. So there is no need to switch on the individual cooking zones manually. The size of the pan is also detected automatically to ensure particularly efficient energy usage.

Safety Functions: For Greater Safety and Security

Best protection in every situation: the system lock provides reliable protection against accidental or unauthorised switching on. If a cooking zone has been operating at the same power level for an unusually long time or there is no pan on the hob, it will switch off automatically. The residual heat indicator is another useful feature: it reminds you not to touch the cooking zones when they are still hot.

Comfortselect

Quick selection via numerical keybank

Powerflex Cooking Area

4 cooking zones incl. 1 high-power

Twinbooster

Shortest heating-up times

Connectivity

Communication with the hood – automatic function

Design:

• Elegant glass ceramic surface
• Ceramic surface colour: Black
• Stainless-steel frame
• Surface-mounted installation

Powerflex Cooking Zones:

• Type: PowerFlex-Kochzone
• Size in mm: 150×230
• Max. rating in W: 2.10
• Max. Booster power rating in W: 3.00
• Max. TwinBooster power rating in W: 3650

1st Cooking Zone/Cooking Area:

• Position: front left
• Type: Dual-circuit ring
• Max. rating in W: 2300
• Max. Booster power rating in W: 3000
• Max. TwinBooster power rating in W: 3650

2nd Cooking Zone/Cooking Area:

• Position: rear centre
• Type: Dual-circuit ring
• Size in mm: 100-160 mm
• Max. rating in W: 1400
• Max. Booster power rating in W: 1700
• Max. TwinBooster power rating in W: 2200

3rd Cooking Zone/Cooking Area:

• Position: right
• Type: PowerFlex bridge
• Size in mm: 230×390
• Max. Booster power rating in W: 4800
• Max. TwinBooster power rating in W: 7300

Efficiency and Sustainability:

• Power rating in off mode in W: 0.50
• Power rating in standby mode in W: 1.00
• Power rating in networked standby in W: 2.00
• Time until automatic switch to off mode in min: 20
• Time until automatic switch to standby in min: 20
• Time until automatic switch to networked standby in min: 20

Safty:

• Safety switch-off
• Lock function
• System lock
• Integrated cooling fan
• Overheating protection
• Residual heat indicator
• Fault monitoring

Technical Data:

• Casing height incl. connection box in mm: 45
• Cutout dimensions in mm (width) with surface-mounted installation: 780
• Cutout dimensions in mm (depth) with surface-mounted installation: 500
• Length of supply lead in m: 1.40

Product Features:

• Networking with Miele home
• Automatic function connectivity 3.0
• Operation via sensor controls: Comfort select
• Display colour: Yellow
• Permanent pan recognition
• Pan and pan size recognition
• Stop & go function
• Recall function
• Minute minder
• Safety switch-off
• Auto heat-up
• Keeping warm
• Individual setting options (e.g. buzzers)
• Digital power level display
• Easy to clean ceramic glass
