Rangemaster 83500 720mm Integrated Extractor Hood in Stainless Steel – REXT720/

The Rangemaster Falcon 83500 Integrated Extractor Hoodoffers a sleek, discreet solution for modern kitchens. Designed to be hidden behind a false chimney or built into existing cabinetry, this 720mm integrated hoodcombines powerful extraction with premium performance and style.

With three fan speedsand an additional boost mode, it delivers flexible ventilation whether you’re simmering or searing. You can control the hood via convenient push-button controls, or for added ease, choose the optional remote control.

The hood can be installed as either a recirculatingor ducted system, making it suitable for a variety of kitchen layouts and ventilation requirements.

Key Features

• Width:720mm
• Installation:Built-in / integrated
• Operation:Push controls or optional remote
• Extraction Settings:3 speeds + boost mode
• Extraction Type:Recirculation or ducted
• Finish:Stainless steel

Combining discreet design with high-performance ventilation, the Rangemaster Falcon 83500 is an ideal choice for integrated kitchen layouts seeking both power and style.

Technical Specifications

• Brand: Rangemaster

• Upgrade Code: P000000000270

Performance

• Flow Rate at BEP: 465 m³/h

• Static Pressure at BEP: 343 Pa

• Electric Power Input at BEP: 223 W

• Grease Filtering Efficiency (GFE): 80%

• Off Mode Power Consumption: 0.85 W

• Effectiveness of the Hob Light: 493 lux

Airflow Rates

• Setting 1 (working point): 360 m³/h

• Setting 1 (free blowing): 370 m³/h

• Setting 2 (working point): 550 m³/h

• Setting 2 (free blowing): 590 m³/h

• Setting 3 (working point): 650 m³/h

• Setting 3 (free blowing): 700 m³/h

• Boost Mode (working point): 785 m³/h

• Boost Mode (free blowing): 850 m³/h

Noise Levels

• Setting 1: 53 dB(A)

• Setting 2: 63 dB(A)

• Setting 3: 67 dB(A)

• Boost Setting: 70 dB(A)

Height – 000 mm

Width – 720 mm

Depth – 000 mm
