Description
TP-LINK’s 5GHz 300Mbps 13dBi Outdoor CPE, the CPE510is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE510 an ideal choice for both business and home users.
- Built-in 13dBi 2×2 dual-polarized directional MIMO antenna
- Adjustable transmission power from 0 to 27dBm/500mw
- System-level optimizations for more than 15km long range wireless transmission
- TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
- Centralized Management System – Pharos Control
- AP / Client / Repeater / AP Router / AP Client Router (WISP) operation modes
- Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely
Antenna
|
|
| Antenna gain level (max) | 13 dBi |
| Antennas quantity | 1 |
| Detachable antenna(s) | |
| Integrated antenna | |
Design
|
|
| Colour of product | White |
| Internal | |
| LED indicators | |
Performance
|
|
| Built-in processor | Qualcomm Atheros Enterprise AR9350B |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Flash memory | 8 MB |
| Frequency band | 5.15 – 5.85 GHz |
| Management platform | Pharos Control |
| Modulation | – |
| Number of users | – user(s) |
Ports & interfaces
|
|
| Ethernet LAN (RJ-45) ports | 2 |
| Interface | Ethernet |
| WAN connection | Ethernet (RJ-45) |
Power
|
|
| Input current | 0.8 A |
| Input frequency | 50 – 60 Hz |
| Input voltage | 100-240 V |
| Power consumption (typical) | 13 W |
| Power over Ethernet (PoE) Support | |
Protocols
|
|
| Management protocols | TDMA |
Security
|
|
| MAC address filtering | |
| Security algorithms | 64-bit WEP,128-bit WEP,152-bit WEP,TKIP,WPA,WPA-PSK,WPA2,WPA2-PSK |
Operational conditions
|
|
| Operating relative humidity (H-H) | 10 – 90 % |
| Operating temperature (T-T) | -30 – 70 °C |
| Storage relative humidity (H-H) | 5 – 95 % |
| Storage temperature (T-T) | -40 – 70 °C |
Other features
|
|
| Colour | |
| Compatibility | PC |
| Transmit power | – dBmW |
| Wireless range | 15000 m |
Packaging content
|
|
| Cables included | AC |
System Requirements
|
|
| Compatible operating systems | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. |
Weight & dimensions
|
|
| Depth | 75 mm |
| Height | 60 mm |
| Width | 224 mm |
